CyberPower SX950U Standby 8 Outlet UPS System
Categories
The CyberPower SX950U uninterruptible power supply (UPS) system provides surge protection for lightning-induced surges and other power events that can damage electronic equipment. This unit delivers enough battery backup to connected electronics during a utility power failure, so you can perform a graceful shutdown to protect against the loss of data and damage to valuable electronics including computers, gaming consoles, and broadband routers.
The SX950U has two USB charging ports with 2.4 amp shared total output which gives you a faster charging time. This unit is designed to minimize noise for a quieter work environment and to run efficiently to reduce power consumption. Including a sleek new design, this UPS is perfect for all your home office and entertainment needs.
Features
- Capacity: 950 VA / 510 W
- Topology: Standby
- Waveform: Simulated Sine Wave
- Output: 120 VAC ± 5%
- Plug type & cord: NEMA 5-15P, 5 ft. cord
- Outlet types: 12 × NEMA 5-15R (6 surge only, 6 surge + battery backup)
- Communication ports: USB (2)
- Management software: PowerPanel® Personal
The batteries have been replaced by the manufacturer as part of the re-conditioning process.
Shipping Note: Shipping to Alaska and Hawaii is not available for this item. A physical address is required for delivery. No Military or PO Box shipments available.
Warranty: CyberPower Warranty
Optional Asurion Protection Plan: To further protect your purchase, you can buy an Asurion protection plan from Amazon here. Review the FAQs for additional information.
The batteries have been replaced by the manufacturer as part of the re-conditioning process.
Technical Details
| UPS Topology | Standby |
|---|---|
| Battery Quantity | 1 |
| Battery Size | 12 V / 7.2 Ah |
| Battery Type | Sealed Lead-Acid Battery |
| Field-serviceable Battery | Replaceable by qualified technician |
| Hot Swappable | No |
| Runtime at Full Load | 2 min |
| Runtime at Half Load | 7.5 min |
| Typical Recharge Time | 8 Hours |
| Circuit Breaker | 15A |
| Cord Length | 5 ft (2 m) |
| Input Frequency Range | 47 Hz – 63 Hz |
| Input Plug Type | NEMA 5-15P |
| Input Voltage | – 120 VAC |
| Nominal Input Voltage | 120 VAC |
| On Battery Frequency | 50/60 Hz ± 1% |
| On Battery Voltage | 120 VAC ± 5% |
| On Battery Waveform | Simulated Sine Wave |
| Outlet Type | NEMA 5-15R |
| Outlets – Battery & Surge Protected | 6 |
| Outlets – Surge-Only Protected | 6 |
| Outlets – Total | 12 |
| Outlets – Widely Spaced | 4 |
| Output Power Factor | 0.53 |
| Overload Protection | Circuit Breaker Protected |
| Typical Transfer Time | 8 ms |
| VA | 950 VA |
| Watts | 510 W |
| EMI/RFI Filtration | Yes |
| Surge Suppression (Joules) | 890 J |
| Audible Alarms | Battery Mode Low Battery Overload Fault |
| HID Compliant USB Port | Yes |
| LED Indicators | Power On |
| Management Cable | USB Cable |
| SNMP / HTTP Remote Monitoring | None |
| Software (Free Download) | PowerPanel® Personal |
| Form Factor | Compact |
| Material of Construction | Plastic |
| Physical Dimensions – (WxHxD) (cm) | 30.99 x 7.87 x 17.78 (cm) |
| Physical Dimensions – (WxHxD) (in) | 12.2 x 3.1 x 7 (in) |
| Physical Dimensions – (WxHxD) (mm) | 310 x 79 x 178 (mm) |
| Weight (kg) | 3.49 |
| Weight (lb) | 7.7 |
| Operating Elevation | 0 – 10000 ft (0 – 3048 m) |
| Operating Relative Humidity | 0 – 95 % (non-condensing) |
| Operating Temperature | 32 – 104 °F (0 – 40 °C) |
| Storage Elevation | 0 – 50000 ft (0 – 15239 m) |
| Storage Relative Humidity | 0 – 95% (non-condensing) |
| Storage Temperature | 5 – 113 °F (-15 – 45 °C) |
In the Box:
- (1) CyberPower SX950U Battery Back-up | 950 VA / 510 W | 12 Outlets | 2 USB Charging Ports
